Mechanical briquette press, briquettes from rape-straw or sawdust Series 34;BriqTech34; model: BT-070-800Max. The principle of the press with a mechanical system with piston actuation - the raw material is pressed without adhesives or binders, forming briquettes (solid fuel) with a density of up to 1450 kg/m3. Briquettes are used in heating plants, fireplaces, stoves, wood-burning ovens, the yield and calorific power is higher than that of firewood and 100 ecological
Technical characteristics of the briquetting press:
Productivity up to: 600 - 900 kg/hour depending on the raw material
Briquette diameter: 70-75 mm plant residues, sawdust (80-85 mm straw)
Lighter length: 100-300 mm
The main briquette press engine - 45 kW
Power motor - 3 kW
Dosing motor – 3 kW
Dosing motor – 3 kW
Total installed power - 55 kW
Three-phase current - 400V, coil voltage 24V/230V within /- 5, frequency 50 Hz
Length: 3300 mm Width: 1550 mm Height: 3200 mm
Briquette machine weight: 4200 kg
Raw material moisture content: 12-14-16
Raw material size: 3 - 8 mm
Density of briquettes at the exit from the mechanical briquetting press briquettes up to 1100 - 1450 kg/m3
Type of raw material: wood sawdust, cereal straw, alfalfa, rapeseed, soybeans, sunflower husks, corn stalks, walnut shell sawdust and other biomass residues containing lignin.
The technology used since 2023
